Fire & Spark
Safety Systems
EWS ALF Series — ultra-sensitive spark detection and precision water extinguishing. Protecting your plant, your people, and your production from fire and explosion risk.
EWS ALF Series — ultra-sensitive spark detection and precision water extinguishing. Protecting your plant, your people, and your production from fire and explosion risk.
In pneumatic conveying systems, blow pipes, chutes, dust filters, silos, and bins — sparks and glowing particles are a constant risk in panel, wood-processing, and bulk-material industries.
A single fire event can cause production stoppage, equipment damage, and in the worst cases, loss of life. The cost of prevention is a fraction of the cost of a single incident.
Developed from decades of field experience and extensive wind-tunnel testing at air velocities up to 36 m/s.
| Parameter | Value |
|---|---|
| Control cabinets | 3, 6, 10, 20, 30, or 40 zones |
| Spark detectors | Up to 70°C / up to 350°C / ATEX Zone 20 |
| Site terminal | Connects up to 4 solenoid valves |
| Response time (DN≤500) | 250 ms |
| Response time (DN500–1000) | 300 ms |
| Response time (DN>1000) | 350 ms |
Watch EWS spark detection and extinguishing technology operating in a real production environment.
Technical specification sheet for the EWS ALF-NANO spark detection and extinguishing system.
Download ALF-NANO DatasheetClarvigo engineers can assess your dust handling and pneumatic conveying systems for spark and fire risk.
Request AssessmentEWS ALF Series detects, reacts, and extinguishes before a spark reaches your filter or silo — fully supervised, zero blind spots.
Request a Risk Assessment
